Allied Bolt - PART# 4095



  • Allied Bolt Suggest Best Practices/installations notes:

MID-SPAN TAKE OFF CLAMP

    • Used to drop cable installations as an attachment to 1/0 - 4/0 ASCR for accepting the bail of Drop Wire Clamps.
    • Clamp is comprised of a set of two jaws with openings to attach bail wires, square head bolt, lock washer, and a hex nut.
    • Bolt and nut are formed from Grade 2 Steel.
    • Jaws are forged from 1045 high strength steel.
    • Bolt is hot dip galvanized to meet ASTM Specification F2329.
    • Jaws, nut, and lock washer are hot dip galvanized to meet ASTM Specification A153.


Standard Packaging Information

Part # Description Pkg Qty Pkg Per Carton Carton Weight
4095 MID-SPAN TAKE OFF CLAMP 40 1 30

schematic
