• Allied Bolt Suggest Best Practices/installations notes:


    • Used in conjunction with a One-Bolt Guy Clamp for supporting strand on exterior walls where more than 3" of clearance is required between cable and wall. Bracket provides a clearance of 8".
    • Mounting holes are 7/16".
    • Center square hole for mounting guy clamp accommodates a 1/2" Carriage Bolt.
    • Stamped from AISI 1018 Steel.
    • Stock size is .187" x 1-1/2".
    • Hot dip galvanized to meet ASTM Specification A153.

Standard Packaging Information

Part # Description Pkg Qty Pkg Per Carton Carton Weight
863 E WALL BRACKET 30 1 46
