• Allied Bolt Suggest Best Practices/installations notes:

10-15MM J BRACKET FOR ADSS FIBER OPTIC CABLE

    • Used to support short or medium length spans of ADSS fiber optic cable on utility poles.
    • The cushioned insert gently grips the cable without causing damage.
    • The maximum vertical load is 2,600 lbs.
    • Hand tighten wing nut to 25 inch pounds.
    • The UV resistant rubber insert provides longevity in all kinds of harsh environments.
    • Can be bolted to utility poles with a 5/8" thru bolts or banded using 3/4" banding.
    • Maximum one-sided angle: fifteen degrees.
    • Bracket is stamped manufactured from AISI 1018 Steel.
    • Bracket is hot dip galvanized to meet ASTM Specification A153.


Standard Packaging Information

Part # Description Pkg Qty Pkg Per Carton Carton Weight
9701-2 10-15MM J BRACKET FOR ADSS FIBER OPTIC CABLE 50 1 20

schematic
